realspace 7164892 - Assembly Preparation and Identification; Required Assembly Tools; Hardware Identification

No. 2 Phillips Screwdriver
Tip Shown Actual Size
Assembly Tools Required
Hammer
Not actual size
2
3
4-14
15-17
18-20
21-22
23
Hardware Identifi cation
Part Identifi cation
Assembly Steps
Français
Español
Safety
Warranty
Table of Contents
Hardware Identifi cation
å Screws are shown actual size. You may receive extra hardware with your unit.
Page 2 www.sauder.com/service 425810
HIDDEN CAM - 46
1
NAIL - 46
5
CAM SCREW - 46
2
METAL PIN - 12
3
APPLIQUE CARD - 3
6
1-3/4" FLAT HEAD SCREW - 4
4
FURNITURE TIPPING RESTRAINT KIT - 1
98
Electric drill with 1/8" bit
(ONLY in indicated step)
