Fasten the LOWER ENDS (C and D) to the BOTTOM (F).
Tighten four HIDDEN CAMS.
Step 5
Page 8 www.sauder.com/service 425810
C
D
F
Surface with HIDDEN CAMS
Surface without HIDDEN CAMS
Surface with HIDDEN CAMS
Edge with HIDDEN CAMS
Edge with HIDDEN CAMS
