Red Kite Sleeptight - Opening the Travel Cot; Unfolding the Frame; Securing the Centre Hub; Placing and Securing the Mattress

To open
1. Remove from the carry bag and pull back the Velcro
straps, remove the mattress and set aside.
Fig 1.
2. Lift the four top folding rails up until they click into
place. Do not push the centre hub down until all four
folding rail locks are fully locked and engaged. The rails
will be horizontal and rigid when this is done correctly.
Fig 2.
NOTE If the folding rails do not click into place easily,
check again that the centre hub is raised. Do not apply
excessive force.
3. When all four folding rails have clicked and locked into
place, lift one end of the cot and firmly press the centre
hub down. The safety lock in the centre hub will then
automatically engage.
Fig 3.
4. Place the mattress inside the travel cot with the
padded side up.
Fig 4.
5. Feed the Velcro straps on the bottom of the mattress
through the corresponding holes on the base of the
travel cot. Attach the straps to the other Velcro
fastening under the cot. This ensures your mattress
remains secured safely. You may need to lift the travel
cot slightly to do this.
Fig 5.
Safety
The travel cot is ready for use, only when the locking
mechanisms are engaged .
Check carefully that they are fully engaged before
using the travel cot .
Fig 1.
Fig 2.
Fig 3.
Fig 4.
Fig 5.
Velcro straps
Centre hub
Folding rail
Folding
joint with
button
underneath
Open
and unfold
the mattress
2. Push centre hub down
1. Spread legs of
travel cot
Velcro tab and strap (x4)
Central folding mechanism
Folding rail
Under side of travel cot
1.
2.
1.
1.
1.
Mattress
Velcro
strap
Folding rail
