Packing List:
The RED LINE
EZ100 J
consists of the following:
o Powder spray gun with a round powder deflector fitted at the tip
of the gun.
o Wall mounting adaptor (Input 100-260V AC 50-60 Hz; output 12
VDC 1.5 amp rating) with 3 meter (10’) cable and a 3 Meter
(10’) earth (ground) cable with crocodile clip
o Two additional round powder flow deflectors of different sizes
(12 mm, 19 mm & 25 mm – ½”, ¾” and 1”) and a starjet nozzle
o 1 cup with a black lid containing a ‘J’ shaped metal pipe and a
screw with washer (ForceFeed Set)
o 1 spare cup with lid
o Or 2 spare cups with lids (in Premium model with carry case)
o This Owner’s Manual
o All securely packed
Infrastructural requirements:
Electrical power connection: 100 - 260 V AC, 50-60Hz, Single
phase with earth (ground). In case of
fluctuating voltage, please use a voltage
stabilizer with surge and spike protection
Pneumatic connection: Clean & dry compressed air at a
pressure of about 1.5 – 2.0 kg/cm
2
(say
20 – 30 psi) – NOT EXCEEDING
3 kg/cm
2
(say 40 psi)
Performance may vary if there is variation in the electrical power
or pneumatic inputs.
