Red Sea MAX S-Series Assembly Instructions

Screw List
Screw # Picture Description Pack Quantity
S1
Round Head
ST 5 x 12mm
Screw Pack A 2 X 50
S2
Countersunk
ST 5 x 14mm
Screw Pack B 28
S3
Countersunk
ST 4 x 35mm
Screw Pack B 6
S8
Round Head
ST 3.5 x 30mm
Screw Pack B 3
S4
Countersunk
M4 x 25mm
Cabinet Parts
Pack
8
S6
Countersunk
4 x 16mm
Hinge Set 24
S3
Countersunk
ST 4 x 35mm
Pipe Clip Pack 3
S5
Countersunk
ST 6 x 16mm
Pipe Clip Pack 2
S7
Countersunk
ST 5 x 35mm
MAX 500
Draw Sliders
4
