47
Fig.1 DRIVE UNIT HE250F (S/N 70200101 and up)
Key# Part Number Description Q'ty
1 848-A4A-5820 PIPE COMP. 1
2 T3207-12200 SHAFT COMP. 1
3 T3207-13000 GEARCASE ASSY 1
4 T3207-13110 • GEARCASE 1
5 6129-13250 • HOLDER-B 1
6 6129-13240 • HOLDER-A 1
7 6129-13211 • SHAFT 1
8 T3207-13310 • PINION 1
9 6129-13220 • GEAR 1
10 06004-06201 • BEARING 1
11 6129-13120 • BEARING 1
12 04065-03212 • SNAPRING 1
13 06001-00609 • BEARING 1
14 06000-00609 • BEARING 1
15 04065-02412 • SNAPRING 1
16 T3300-13330 • SNAPRING FOR ø9 SHAFT 1
17 T3002-13260 • NUT 1
18 3199-13350 • FITTING, GREASE 1
19 01641-20608 • WASHER, FITTING 1
20 T3207-13260 • BOLT 1
21 01252-30510 • BOLT 1
22 848-J80-32H2 GRIP 1
23 848-8R2-0344 LEVER COMP. 1
24 848-8R2-0314 • LEVER (FLEX. LEVER) 1
25 848-8RA-0340 • • COVER, LEVER 1
26 T3002-12220 • CORD(A) BLACK 1
27 T3002-12230 • CORD(B) RED 1
28 T3002-12240 TUBE 1
29 T3002-83100 CABLE COMP. 1
30 848-A4A-90R0 NAME PLATE 1
32 T3195-14002 HANDLE ASSY 1
33 T3195-14102 • HANDLE COMP. 1
34 T4960-53030 • SCREW 4
35 T3207-24000 GUARD ASSY 1
36 848-A47-66A1 • GUARD 1
37 T3207-24130 • BOLT 5
38 T3207-24150 • PLATE 1
39 T3207-24210 • PLATE, PROTECTOR 1
40 0280-10504 • NUT 2
41 848-A47-66P0 • WHEEL 1
42 T3207-25170 • BOLT 1
43 01602-20825 • WASHER, SPRING 1
44 01642-20810 • WASHER, PLANE 2
45 01540-50840 • WING NUT 1
46 T3207-25160 • SLEEVE 1
Key# Part Number Description Q'ty
47 T3207-24310 • BRACKET 1
48 T3207-24320 • PLATE, RUBBER 1
49 T3207-24330 • RUBBER 1
50 01252-30510 • BOLT 2
55 6367-15110 BLADE 1
To Next Page
