Fig.2 ENGINE UNIT HE250F (S/N 70200101 and up)
Key# Part Number Description Q'ty
1 6634401 SCREW 4
2 3075406 FRONT HOUSING 1
3 6635301 SCREW CLUTCH 2
4 6969601 WASHER CURVED 2
5 3075603 CLUTCH ASSY 1
6 6969501 WASHER PLAIN 2
7 6968901 NUT 1
8 6457403 ROTOR 1
9 4309501 CRANKCASE&SHAFT ASSY 1
10 6968501 • BEARING 2
11 5987501 • SEAL 1
12 9071301 GASKET CASE 1
13 6968401 • RING 1
14 5687401 • SEAL 1
15 6634801 • SCREW 3
16 3075003 • CRANKCASE ASSY 1
17 3090101 CRANKSHAFT ASSY 1
18 6457303 PISTON 1
19 6969001 RING 2
20 6969101 CLIP RING 2
21 6968701 WASHER 2
22 6997001 NEEDLE BEARING 1
23 6230101 WRIST PIN 1
24 6968801 KEY 1
25 4300401 PULLEY ASSY 1
26 6634701 BOLT MAFFLER 2
27 3074802 MUFFLER & arrester 1
28 6300206 MUFFLER GASKET 1
29 6457003 CYLINDER 1
30 9071102 GASKET INSULATOR 1
31 6634502 SCREW TORX 1
32 5994702 INSULATOR 1
33 9071103 GASKET CABURETOR 1
34 6634402 SCREW TORX 2
35 3074502 CARBURETOR 1
36 6970001 CLIP HOSE 1
37 6969901 CLIP HOSE 1
38 5688002 PLASTIC RUBBER TUBING 1
39 3078001 PRIMER ASSY 1
40 3097402 CHOKE LEVER&PLATE ASSY 1
41 6634501 • SCREW TORX 1
42 5994601 • CHOKE PLATE 1
43 4315001 • CARBURETOR PLATE 1
44 5945801 • CHOKE LEVER 1
45 6634601 BOLT CARBURETOR 2
46 5687301 ELEMENT 1
Key# Part Number Description Q'ty
47 3099904 COVER ASSY 1
48 5946101 KNOB 1
49 9506501 DECAL 1
50 9506009 DECAL(To Start) 1
51 9506011 DECAL(caution) 1
52 8714402 SPARK PLUG 1
53 6634201 CAP SCREW 2
54 6635102 SCREW TORX 2
55 6300221 PLATE FIN 1
56 9070901 GASKET CYLINDER 2
57 5947001 REAR HOUSING 1
58 6656301 SCREW TORX 3
59 3075304 RECOIL ASSY 1
60 6635101 SCREW TORX 4
61 9506401 DECAL STARTER 1
62 9506010 DECAL(E Start) 1
63 9509001 DECAL(EMISSION) 1
64 3075804 TANK&CAP ASSY 1
65 3075705 • TANK ASSY 1
66 3075904 • • FILTER 1
67 5687901 • • PlPE RETURN 1
68 5688001 • • PlPE FUEL 1
69 5687801 • • TANK GROMMET 1
70 5835901 • • TANK 1
71 6976501 • • CLIP 1
72 3075803 • CAP ASSY 1
73 6635401 BOLT TORX 3
74 6634901 BOLT TORX 2
75 2917803 COIL&BOOT ASSY 1
76 2914301 LEAD ASSY(BLACK) 1
77 2914302 LEAD ASSY(RED) 1
78 5946201 SPACER 2
79 6996901 WASHER 2
80
848-EU0-53D0
CUSHION 1
81 01252-30630 BOLT 1
82 1565-12140 NUT 1
83 2630-31950 SCREW 1
84 1484-86280 WASHER 1
85 5883-32160 SCREW 1
