P/L-3
TR2350S
Fig.1 DRIVE UNIT TR2350S (S/N 90200101 and up)
14. Parts list
Key# Part Number Description Q'ty
1 848-J8S-5820 PIPE COMP. 1
2 T3400-12130 • SEAL 1
3 3520-12213 SHAFT 1
4 848-JC0-6100 GEARCASE ASSY 1
5 6440-13122 • GEARCASE 1
6 04065-02612 • SNAP RING 1
7 3565-13130 • SEAL 1
8 T3002-13260 • NUT 1
9 848-JC0-61D0 • PINION 1
10 T3300-13531 • BEARING 1
11 T3403- 13530 • BEARING (0600000609) 1
12 T3300-13330 • SNAP RING 1
13 04065-02412 • RING (0243224120) 1
14 T4950-52500 • BOLT TORX, 5x25 1
15 6440-13242 • HOLDER (A) 1
16 3199-13350 • FITTING (2087061640) 1
17 01641-20608 • WASHER 1
18 T4950-51200 • BOLT TORX, 5x12 1
20 848-8R4-0600 GRIP ASSY 1
21 848-BRA-0391 • BODY-R 1
22 848-8RB-0391 • BODY-L 1
23 848-8RC-0600 • LEVER, THROTTLE 1
24 848-8RJ-0600 • SPRING, THROTTLE 1
25 848-8RD-0600 • LEVER, SAFETY 1
26 848-JL2-33F3 • SPRING 1
27 848-8RE-0600 • LEVER, JOINT 1
28 T4506-52110 • SWITCH 1
29 848-824-1600 • SCREW 4
30 848-8P4-0550 • CABLE COMP. 1
31 848-8M1-0820 • CORD COMP. 2
32 T3003-14510 • TUBE 1
33 848-8RH-0421 • BAND 2
35 4820-13180 • BOLT 2
36 848-860-5000 • NUT 2
42 T3300-17202 HANGER COMP. 1
43 848-805-2000 SCREW TORX, 5x20 1
44 848-J7G-90R0 LABEL, NAME 1
45 848-8X1-0040 LABEL, CAUTION 1
46 T3195-14002 HANDLE ASSY 1
47 T4960-53030 • SCREW TORX, 5x30 4
48 848-J6M-6600 GUARD ASSY 1
49 T3338-24100 • GUARD ASSY 1
50 6041-24140 • • BLADE 1
51 0263-90516 • • SCREW 2
52 3320-15310 • • NUT 2
53 3520-24120 • CLAMP 1
Key# Part Number Description Q'ty
54 T4950-63000 • BOLT TORX 2
55 PT104 Plus TAP HEAD COMP. 1
56 848-BU3-69M4 • CASE 1
57 T3189-15191 • EYELET 2
58 T3189-15132 • COVER 1
59 T3189-15142 • CORD HOLDER 1
60 T3189-15160 • SPRING 1
61 848-BU3-69S0 • CORD 1
62 848-8U0-0140 TOOL-SET 1
63 3540-91110 • BAR 1
64 848-8U1-0050 • SOCKET 1
65 T3195-91110 BAG 1
66 848-A56-92C0 GOGGLE 1
101 5764-24000 GUARD ASSY 1
102 5766-24110 • GUARD 1
103 3250-24120 • BRACKET 1
104 0225-10620 • BOLT 2
105 0263-30614 • SCREW 4
106 0280-10605 • NUT 4
107 3540-13283 COVER 1
108 6367-14200 J-HANDLE 1
109 3583-14101 BRACKET ASSY 1
110 848-J82-3610 STRAP ASSY 1
121 SST229 9" 22-tooth 1
122 SST249 9" 24-tooth 1
123 SGB088 8" 8-tooth 1
124 SGB089 9" 8-tooth 1
125 SGB048 8" 4-tooth 1
126 SGB049 9" 4-tooth 1
OPTIONAL BLADE & ACCESSORIES
