Key# Part Number Description Q'ty
1 848-E3Y-12A0 CYLINDER 1
2 T1600-12210 GASKET 1
3 1850-12130 BOLT M5x22 2
4 3699-90332 PLUG BPMR7A 1
5 T1600-21100 CRANKCASE COMP. 1
6 2629-21130 • PIN
7 T1600-21140 GASKET, CASE 1
8 T1600-21240 BEARING 2
9 T1600-21210 SEAL 1
10 T1600-21220 SEAL 1
11 04065-02612 RING ø26 1
12 01252-30520 BOLT M5x20 3
13 T1600-42003 CRANKSHAFT COMP. 1
14 1160-41110 PISTON 1
15 1100-41210 RING 1
16 1101-41310 PIN 1
17 1260-41320 RING 2
18 5500-41410 BEARING 1
19 1101-41340 WASHER 2
20 848-E4B-1510 MUFFLER ASSY 1
21 4810-15140 • ARRESTER 1
22 01252-30550 BOLT M5x50 2
23 T1600-15210 GASKET 1
24 T1600-15221 PLATE 1
25 T1600-13100 INSULATOR COMP. 1
26 0282-10604 • NUT 1
27 T1600-13170 • SCREW 1
28 5500-13121 GASKET 1
29 5500-13131 GASKET 1
30 5500-85510 SCREW M5x16 2
31 848-E48-8100
CARBURETOR ASSY WYL-221
1
32 0263-90550 SCREW M5x50 2
33 T1600-82100 BODY ASSY 1
34 1970-82190 • SLEEVE 1
35 T1600-82130 • PLATE, choke 1
36 T1600-82140 • LEVER, choke 1
37 2630-33610 • SCREW 1
38 5500-82171 ELEMENT 1
39 T1600-82200 COVER ASSY 1
40 5500-82221 • KNOB 1
41 848-E3L-53A0 HOUSING 1
42 848-F30-51A1 DRUM 1
43 04064-01210 SNAP RING 1
44 T1700-31212 BRACKET (A) 1
45 T1700-31221 BRACKET (B) 1
46 T1700-31232 CUSHION 1
47 01252-80522 BOLT 2
48 01252-80510 BOLT 1
49 T1600-72210 CLAMP 1
Key# Part Number Description Q'ty
50 5500-85510 SCREW M5x16 4
51 848-E34-31A1 COVER, ENGINE 1
52 0263-90510 SCREW 1
53 5500-85510 SCREW M5x16 2
54 848-EA0-5110 SHOE COMP. 1
55 T1600-51220 • SPRING 1
56 1140-51250 SCREW 2
57 1140-51230 WASHER 2
58 1970-51241 WASHER 2
59 848-E48-71A0 ROTOR 1
60 848-E48-7121 COIL ASSY 1
63 3350-14150 BOLT M4x20 2
64 1260-71261 SPACER 2
65 T1600-73200 CORD COMP. 1
66 2750-32620 NUT 1
67 T1600-75100 RECOIL ASSY 1
68 T1600-75120 • REEL 1
69 4500-75150 • SCREW 1
70 T1600-75130 • SPRING 1
71 4500-75180 • COLLOR 1
72 T1600-75190 • ARM 1
73 T1600-75160 • ROPE 1
74 T1600-75310 • KNOB 1
75 T1600-75321 • COLLOR 1
76 T1600-75330 • SPRING 1
77 4820-75210 • WASHER 1
78 4500-75210 PULLEY 1
79 5500-85510 SCREW 2
80 848-E4B-8500 TANK ASSY 1
81 5607-85201 • CAP ASSY 1
82 5601-85300 • • HOLDER ASSY 1
83 5500-85220 • • PACKING 1
84 5601-85260 • • FILTER 1
85 4820-85260 • • STOPPER 1
86 4810-85300 • PIPE COMP. 1
87 5500-85400 • FILTER 1
88 1260-85460 • CLIP 1
89 5500-85510 SCREW 3
90 1950-86120 CLIP 1
– LABEL, RECOIL 1
92 848-8X1-0100 LABEL, CAUTION 1
P/L-5
TR2350S
Fig.2 ENGINE UNIT TR2350S (S/N 90200101 and up)
