Redtech TRAILERteck T05 - 15-Function Remote

5
15-function remote
#
Label
Electrical
cord
Description
1
TAIL
Brown
Activates TAIL lights
2
MARKER
Black
Activates MARKER lights
3
LEFT
Yellow
Activates LEFT lights
4
RIGHT
Green
Activates RIGHT lights
5
AUX
Blue
Activates Auxiliary
6
BRAKE
Red
Activates BRAKE lights or electrical brakes
7
EMER
Air valve
Send air to the trailer tanks
8
SERVICE
Air valve
Applies and releases BRAKES. Emergency
function has to be activated for the service
function to work.
1 – 2
Brown and
Black
Activates both TAIL and MARKER lights at the
same time
3 – 4
4 WAY
Yellow and
Green
Activates the 4-way flashers
OPTION
n/a
For optional made to measure
ALARM
n/a
Audible signal coming from the device
SEQ
n/a
To follow a defined sequence using a single
button
FREEZE
n/a
For safety purposes. Hold 5 seconds to freeze
/unfreeze the remote and the device
PROG
n/a
To program a new remote with the device
