REED PPR75 - Plastic Pipe Fitting Reamer Assembly and Operation; Assembly Procedure; Operating Instructions and Safety Precautions

ASSEMBLY
1. Insert Shaft into Body.
2.Makesureshaftisallthewaythroughandushwiththe
bottom of the reamer.
3. Using a 1/8” Allyn wrench, tighten set screw.
Note: These reamers can be used with standard drills, cord-
less drills, or impact drills. For most effective use, run the drill
at a low or medium RPM.
WARNING:3”and4”ttingreamerscreatealargereaction
torque that can cause injury to operator, therefore a standard
1/2” right angle drill is recommended. Use caution when using
these tools. For reaming 3” or 4”, a lower RPM is recommend-
edtoreduceheatandpossibledistortionofthetting.
Plastic Pipe Fitting Reamers Operating Instructions
PPR75, PPR100, PPR125, PPR150, PPR200, PPR300, PPR400
INSTRUCTIONS
1.Cutdamagedpipeasclosetottingaspossible.
2.Selectpropersizettingborer,putitindrillchuck,
and tighten. A standard 1/2” right angle drill is
recommended.
3.Insertttingreamer into broken pipe, ensure tool stays
on center to prevent binding. If no chips are being
made, remove tool and check.
4. Ream old pipe until proper depth is attained.
5.Removedrillandcleanoutchipsfromtting.
NOTE: PPR Fitting Reamers are NOT recommended
for use on pressurized systems.
Reed Manufacturing Company
1425 West 8th Street
Erie, PA 16502 USA
Phone: 800-666-3691 or 814-452-3691
Fax: 800-456-1697 or 814-455-1697
www.reedmfgco.com
54521-213
See Also: RP-0113-103
