Device descriptio baby unit/parent unit Symbol and display
Difference between child and parental unit consists of the motif on the child unit.
Reception: device receives sounds of other unit. Can be heard through
loudspeaker.
Transmission: The transmission (PTT) button is pressed and the device trans-
mits in automatic mode (VOX see below)
Roger Beep is activated.
Key tones are activated.
Keypad lock is activated.
Range control is activated (automatically: AU or manually: Pb)
Search: Device searches channels (only in walkie talkie mode).
Battery status indicator: 3 lines = battery is fully charged, 1 line = battery is
almost discharged (check during or immediately after broadcast!)
„Parent“ symbol: parental unit. The device is set as the parent unit. It does
not appear in walkie talkie mode (PMR446).
„Baby“ symbol: Child unit. The device is set as the child unit. It does not
appear walkie talkie mode (PMR446).
VOX
Intelligent audio activation (VOX) is activated: the device is transmitting
automatically (without pressing the PTT button) if a sound is heard in the
baby‘s room.
CT
CTCSS is activated.
DC
DCS is activated.
Status LED
PTT button
Intercom function
Connections for accessories, e.g.
cable microphone
Menu button
Keypad lock
On/Off
Range control
Safety lock by means of screw
on the battery compartment
Removable
belt clip
Volume
Select up
Volume
Select down
Micro USB charging input
Noise level indicator (parental
unit)/Night light (child unit)
MON button
