MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
48 8540780 • 10/07/2020 • Rev.38
M1S module
Digital INPUTS (No./description)
8 / PNP active high according to EN 61131-2
INPUT FBK/RESTART
(No./description)
Up to 4 / EDM control / possible Automatic
or Manual operation with RESTART button
Test OUTPUT (No./description)
4 / to check for short-circuits - overloads
SIL 1/PL c OUTPUTS (No./description)
Up to 4 / programmable - PNP active high
4 single / solid state safety outputs PNP active high
400mA@24VDC max
Interface type C class 3 (ZVEI CB24I)
USB 2.0 (Hi Speed) - Max cable length: 3m
Connection to slave units
via MSC 5-way ReeR proprietary bus
MI8O2 module
Digital INPUTS (No./description)
8 / PNP active high according to EN 61131-2
INPUT FBK/RESTART (No./description)
2 / EDM control / possible Automatic
or Manual operation with RESTART button
Test OUTPUT (No./description)
4 / to check for short-circuits - overloads
SIL 1/PL c OUTPUTS (No./description)
2 / programmable - PNP active high
2 pairs / solid state safety outputs:
PNP active high 400mA@24VDC max
Interface type C class 3 (ZVEI CB24I)
via MSC 5-way ReeR proprietary bus
MI8O4 module
Digital INPUTS (No./description)
8 / PNP active high according to EN 61131-2
INPUT FBK/RESTART
(No./description)
Up to 4 / EDM control / possible Automatic
or Manual operation with RESTART button
Test OUTPUT (No./description)
4 / to check for short-circuits - overloads
SIL 1/PL c OUTPUTS (No./description)
Up to 4 / programmable - PNP active high
4 single / solid state safety outputs:
PNP active high 400mA@24VDC max
Interface type C class 3 (ZVEI CB24I)
via MSC 5-way ReeR proprietary bus
