Reflexion DVD9325 - Page 23

Technical details DVD9325 Energyefficiency
Display technology LCD/TFT
Screen size, visible 9 Inch (22,9 cm)
Screen format 16:9
Resolution 640 x 234
Minimum contrast ratio 500:1
Minimum brightness 120 cd/m²
Display colors 16.7 M colors
Minimum viewing angle 70° (horizontal) / 65° (vertical)
Maximum response time 25 ms
Picture repetition rate 50 Hz
Video color systems PAL / NTSC
Chanels (DVB-T) 1000
TV Functions
Videotext (DVB-T) 999 Pages
USB 1
SD CARD SLOT 1
AV OUT 1
COAXIAL 1
DVB-T ANT. JACK 1
EARPHONE OUTPUT 1
DC 9-12 V INPUT 1
Connections
Main unit
DC 9-12 V OUTPUT 1
AV IN 1
EARPHONE OUTPUT 1
Connections
Slave unit
DC 9-12 V INPUT 1
Audio output 2 x 1 Watt
Gross weight 1.38 KG
Power requirement DC 9-12V, 1.5A,
AC 110~240V, 50Hz/60Hz
Power consumption maximum 15 W
Power consumption „ON“ for EN 62087 10 W
Peak luminance ratio in % 50 %
Accu LI-ION / 1200mAh
10
