UK
48
SCOPE OF DELIVERY
 Device
 Remote control
incl. batteries
 12V car adapter
 Power supply
 Active DVB-T
antenna
 TV stand incl. screws
 User manual
 4x M4 Vesa screws
MOUNTING WALL BRACKET & STAND
Wall bracket:
The TV set is equipped with mounting points (M4) for a wall bracket (wall bracket not included).
The VESA hole spacing is 100x100 (Vesa100). Do not use screws that are too long as you could
damage components inside the device.
Note:
 Follow the instructions for the wall bracket during installation.
 Consult a professional for the installation of the wall bracket if you have any
questions.
Assembly TV stand:
PICTURE 1
Screws C
B Middle piece
A Back view
