REICH Move Control 527-0521 User Manual

Anschlußplan Aansluitschema Connecting diagram Plan de connexion
6 mm²
+
-
+
+
-
-
Detail
Detail Motor
 = PLUS
+
-
10 mm²
min. 75 Ah
6 mm²
6 mm²
10 mm²
+
-
min. 75 Ah
-
+
6 mm²
-
-
Ebox + (Plus) = Motor (Minus)
Ebox (Minus) = Motor + (Plus)
MoveControl
LED
Reset
E-Box
- R + - L + - 12V +
D-Plus
+
-
Motor
Drive
E-Box
- R +
- L + - 12V +
D-Plus
+
-
Motor
Drive
D-Plus Signal
(optional)
D-Plus Signal
(optional)
l
55
