Relish TOUCH CONTROL - Pickup Position LED Indication Guide; LED Color Meanings; Pickup Indication Examples

Neck Pickup
coil split mode
activated
Bridge Pickup
coil split mode
activated
Bridge Pickup
activated only
Neck & Bridge
Pickups both
activated,
50/50 mix
Neck Pickup
activated only
PICKUP POSITIONS RGB LED INDICATION
When Touch Control System is active, RGB LED lights will indicate the posi-
tion or mix of the pickups in use.
Blue light indicates coils of respective pickup are split.
Red light indicates battery is low (below 10%).
Neck & Bridge
Pickups both
activated,
20/80 mix
Neck & Bridge
Pickups both
activated,
80/20 mix
Neck & bridge
pickup in coil
split mode,
50/50 mix
White light indicates position of neck-bridge mix.
PICKUP POSITION INDICATION EXAMPLES
TECHNICAL SUPPORT
If you have any questions or face any technical issues, please do not hesitate
to contact us at
info@relish.swiss
Page 4/5
