FEB 03/06 REVISION #1
3-POINT DELTA PARTS LIST
(4', 6', 8', 10', 12', 14' UNITS)
PART NUMBER DESCRIPTION #/UNIT
A. 10-104325 3 POINT HITCH FRAME 2
B. 10-104328 CROSS-BRACE ASSEMBLY 1
C. 10-104335 SIDE FRAME ASSEMBLY 2
D. 10-104331 TOP BRACKET ASSEMBLY 1
E. 10-104858 4' PULL BAR 1
10-104336 6' PULL BAR 1
10-104337 8' PULL BAR 1
10-104338 10' PULL BAR 1
10-104339 12' PULL BAR 1
10-104340 14' PULL BAR 1
F. 10-104859 4' REAR LIFT BAR 1
10-104341 6' REAR LIFT BAR 1
10-104342 8' REAR LIFT BAR 1
10-104343 10' REAR LIFT BAR 1
10-104344 12' REAR LIFT BAR 1
10-104345 14' REAR LIFT BAR 1
G. 6735-00-0001 PIN 3PT. 7/8" 2
H. 10-104823 LIFT - UPPER 2
I. 10-101775 CHAIN LIFT SEGMENTS (4' UNIT) 5
CHAIN LIFT SEGMENTS (6' UNIT) 6
CHAIN LIFT SEGMENTS (8' UNIT) 8
CHAIN LIFT SEGMENTS (10' UNIT) 9
CHAIN LIFT SEGMENTS (12' UNIT) 10
CHAIN LIFT SEGMENTS (14' UNIT) 12
K. 4001-22C2550 3/8" x 3" HEX BOLT UNC GR.5 2
5009-02-0375 3/8" FLAT WASHER 2
5000-63-0375 3/8" LOCK WASHER 2
4030-21C0235 3/8" HEX NUT UNC GR.5 2
