REMS CamScope Series User Manual

2. Start-up
2.1. Handheld unit (5)
Remove the screw from the battery compartment (17) of the handheld unit (5)
(only in REMS CamScope), push the cover in the direction of the arrow to
remove, remove the battery holder, insert 4 1.5 V, AA, LR6 batteries into the
battery holder, pay attention to the position of the plus-minus poles. Push the
battery holder back into the battery compartment, slide in the cover, screw in
the screw (only in REMS CamScope). Always change all four batteries at once.
2.2. Camera cable set Color (2)
Plug the camera cable set Color into the cable socket (3) of the handheld unit
(5). Position the strap of the camera cable set in line with the groove of the
handheld unit. Tighten the camera cable set hand-tight with the union nut of
the handheld unit.
The tools, add-on mirror, add-on hook, add-on magnet delivered with the camera
cable set Color 16-1 only t the camera cable set Color 16-1 and are clipped
optionally to the camera head. Always close the ap otherwise the tool could
be lost.
The enclosed accessory set does not t camera cable set Color 9-1. First push
the plastic sleeve over the wire of the tool of the add-on mirror, add-on hook
or add-on magnet. Hook the hook of the tool on the camera head into the hole
in the camera housing marked by an arrow. Align the plastic sleeve so that the
eng eng
1.1. Supply format Set 16-1 Set 9-1 Set 4,5-1
REMS CamScope 175110 175111 175112
* Supply format * Supply format * Supply format
Camera cable set Color 16-1 Camera cable set Color 9-1 Camera cable set Color 4,5-1
Add-on mirror, add-on hook Add-on mirror, add-on hook
Add-on magnet Add-on magnet
REMS CamScope S 175130 175131 175132
* Supply format * Supply format * Supply format
Camera cable set Color 16-1 Camera cable set Color 9-1 Camera cable set Color 4,5-1
Add-on mirror, add-on hook Add-on mirror, add-on hook
Add-on magnet Add-on magnet
REMS CamScope Wi-Fi 175140 175141 175142
Handheld unit Handheld unit Handheld unit
4 1.5 V, AA, LR6 batteries 4 1.5 V, AA, LR6 batteries 4 1.5 V, AA, LR6 batteries
Camera cable set Color 16-1 Camera cable set Color 9-1 Camera cable set Color 4,5-1
Add-on mirror, add-on hook Add-on mirror, add-on hook Operating instruction, case
Add-on magnet Add-on magnet
Operating instructions, case Operating instructions, case
* Supply format:
Handheld unit, 4 batteries 1.5 V, AA, LR6, controller unit, MicroSD-card 2 GB, power supply/charger unit, USB cable, video cable, case
1.2. Article numbers
Camera cable set Color 16-1 175103
Camera cable set Color 16-1 90° 175106
Camera cable set Color 9-1 175104
Camera cable set Color 4.5-1 175102
900 mm push cable extension 175105
REMS CleanM 140119
1.3. Handheld unit REMS CamScope REMS CamScope S REMS CamScope Wi-Fi
Wi-Fi standard IEEE 802.11 b/g/n
Transmission frequency 2468 MHz 2468 MHz 2.4 GHz
Pixel image transfer 640 × 480
Modulation FM FM
Bandwidth 18 MHz 18 MHz
Wireless range up to 10 m up to 10 m up to 10 m
Power supply 4 batteries 1.5 V, AA, LR6 4 batteries 1.5 V, AA, LR6 4 batteries 1.5 V, AA, LR6
Dimensions 190 × 140 × 40 mm 190 × 165 × 53 mm 245 × 130 × 43 mm
Weight 260 g 320 g 250 g
1.4. Controller unit REMS CamScope REMS CamScope S REMS CamScope Wi-Fi
Display 3.5” colour TFT-LCD 3.5” colour TFT-LCD see operating instructions
Pixels (display) 320 × 240 320 × 240 Smartphone/Tablet-PC
Pixels (recording) 640 × 480 640 × 480
Video system PAL / NTSC PAL / NTSC
Reception frequencies 2414, 2432, 2450, 2468 MHz 2414, 2432, 2450, 2468 MHz
Transmission channel not adjustable not adjustable
Battery integrated Li-Ion battery 3.7 V, 1.2 Ah integrated Li-Ion battery 3.7 V, 1.2 Ah
Power supply/charger 100 – 240 V AC, 50 – 60 Hz, input / 100 – 240 V AC, 50 – 60 Hz, input /
5 V DC, 1 A, output, protection class II DC 5 V / 1 A, output, protection class II
Video level 0.9 – 1.3 Vpp on 75 Ohm 0.9 – 1.3 Vpp on 75 Ohm
Video size 27 MB per minute 27 MB per minute
Frame rate up to 30 frames per second up to 30 frames per second
Zoom 1.5 / 2.0 / 2.5 / 3.0 × 1.5 / 2.0 / 3.0 ×
Dimensions 100 × 70 × 25 mm 105 × 90 × 42 mm
Weight 150 g 240 g
Temperature range –10°C ... +50°C / +14°F ... +122°F –10°C ... +50°C / +14°F – +122°F
Humidity 15 – 85% RH 15 – 85% RH
Tested units for see www.REMS.de under
REMS application software DOWNLOADS/Software/Compatibility
1.5. Camera cable set Color 16 mm camera 16 mm camera, 90° 9 mm camera 4.5 mm camera
Image sensor CMOS CMOS CMOS CMOS
Number of pixels 704 × 576 656 × 488 640 × 480 320 × 240
Viewing angle 50° 35° 36° 63°
Focus range 60 – 350 mm 35 – 80 mm 20 – 100 mm 10 – 50 mm
Min. lighting 0 Lux 0 Lux 0 Lux 0 Lux
Power supply by handheld unit by handheld unit by handheld unit by handheld unit
Dimensions Ø 16 × 970 mm Ø 16 × 970 mm Ø 9 × 970 mm Ø 4.5 × 1030 mm
Weight 280 g 185 g 190 g 30 g
Video format PAL PAL PAL NTSC
Type of protection camera IP 67 IP 67 IP 67 IP 67
≤ 30 min, ≤ 0.1 bar ≤ 30 min, ≤ 0.1 bar ≤ 30 min, ≤ 0.1 bar ≤ 30 min, ≤ 0.1 bar
