FUSES (2/2)
Allocation of fuses
(the presence of certain fuses depends on the vehicle equipment level)
Symbol Allocation Symbol Allocation
H
Windscreen washer
Not used
ë
Third row accessories socket, boot accessories
socket
Ý
Towbar socket
Æ
Front cigarette lighter, front and rear second row
accessories socket
Diagnostic socket, audio alarm
Not used
Ì
Horn
Heated door mirrors
Instrument panel, dashboard control lighting
×
Brake lights, passenger compartment central unit
Piloted dampened suspension
Parking brake
f
Front windscreen wiper
Additional servo
D
Direction indicator lights, hazard warning lights
î
Radio, multifunction screen, multimedia acces-
sories sockets, parking brake control
Rear USB sockets on console
Passenger compartment centre unit, rear wiper,
rear fog light
Not used
O
Locking opening elements, tailgate opening and
closing control
