ADC_TRIG_SYNC_TRG0EN = 4, // MTU0 TRGE
ADC_TRIG_SYNC_TRG0FN = 5, // MTU0 TRGF
ADC_TRIG_SYNC_TRG4AN = 6, // MTU4 TADCORA
ADC_TRIG_SYNC_TRG4BN = 7, // MTU4 TADCORB
ADC_TRIG_SYNC_TRG4AN_AND_TRG4BN = 8, // MTU4 TADCORA and MTU4 TADCORB
ADC_TRIG_SYNC_ELC = 9, // ELC
ADC_TRIG_SOFTWARE = 10, // software trigger; not for Group modes
// nor double trigger modes
// This is not set to TRSA or TRSB
ADC_TRIG_NONE = 0x3F
} adc_trig_t;
typedef enum e_adc_speed
{
ADC_CONVERT_SPEED_DEFAULT = 0,
ADC_CONVERT_SPEED_HIGH = 0,
ADC_CONVERT_CURRENT_LOW = 1
} adc_speed_t;
typedef struct st_adc_cfg
{
adc_speed_t conv_speed; // ADCSR.ADHSC, rx130 has two conversion
speeds
adc_align_t alignment; // ADCER.ADRFMT, Left or Right
alignment,ignored if addition used
adc_add_t add_cnt; // ADADC.ADC, Addition/average count
select.
adc_clear_t clearing; // ADCER.ACE, Automatic clearing
enable/disable after read
adc_trig_t trigger; // ADSTRGR.TRSA, default and Group A
trigger source
adc_trig_t trigger_groupb; // valid only for group modes
uint8_t priority; // for S12ADIO int; 1=lo 15=hi 0=off/polled
uint8_t priority_groupb; // S12GBADI interrupt priority; 0-15
} adc_cfg_t;
/***** ADC_CONTROL() ARGUMENT DEFINITIONS *****/
typedef enum e_adc_cmd
{
// Commands for special hardware configurations
ADC_CMD_USE_VREFL0, // Low reference. Default is to use AVSS0.
ADC_CMD_USE_VREFH0, // High reference. Default is to use AVCC0.
ADC_CMD_SET_DDA_STATE_CNT, // For Disconnect Detection Assist
ADC_CMD_SET_SAMPLE_STATE_CNT, // Set the conversion time
// Command to configure channels, sensors, and comparator
ADC_CMD_ENABLE_CHANS, // Configure channels to scan
ADC_CMD_ENABLE_TEMP_SENSOR, // "configure" temperature sensor
ADC_CMD_ENABLE_VOLT_SENSOR, // "configure" internal ref voltage sensor
ADC_CMD_EN_COMPARATOR_LEVEL, // Enable comparator for threshold compare
ADC_CMD_EN_COMPARATOR_WINDOW, // Enable comparator for range compare
// Commands to enable hardware triggers or cause software trigger
ADC_CMD_ENABLE_TRIG, // ADCSR.TRGE=1 for sync/asynchronous
triggers
ADC_CMD_SCAN_NOW, // Software trigger start scan
// Commands to poll for scan completion and comparator results
