} adc_data_t;
2.10.9 RX63x Interface Types (r_s12ad_rx63x_if.h)
/* ADC_OPEN() ARGUMENT DEFINITIONS */
typedef enum e_adc_mode
{
ADC_MODE_SS_TEMPERATURE, // single scan temperature sensor
ADC_MODE_SS_INT_REF_VOLT, // single scan internal ref voltage sensor
ADC_MODE_SS_ONE_CH, // single scan one channel
ADC_MODE_SS_MULTI_CH, // 1 trigger source, scan multiple channels
ADC_MODE_CONT_ONE_CH, // continuous scan one channel
ADC_MODE_CONT_MULTI_CH, // continuous scan multiple channels
ADC_MODE_MAX // This definition DO NOT USE for R_ADC_Open() argument
} adc_mode_t;
typedef enum e_adc_trig // trigger sources (set to ADSTRS bit)
{
ADC_TRIG_ASYNC_ADTRG = 0, // ADTRG#0
ADC_TRIG_SYNC_TRG0AN = 1, // MTU0 TRGA
ADC_TRIG_SYNC_TRG0BN = 2, // MTU0 TRGB
ADC_TRIG_SYNC_TRGAN = 3, // MTUx TRGA
ADC_TRIG_SYNC_TPUTRGAN = 4, // TPUx TRGA
ADC_TRIG_SYNC_TRG0EN = 5, // MTU0 TRGE
ADC_TRIG_SYNC_TRG0FN = 6, // MTU0 TRGF
ADC_TRIG_SYNC_TRG4AN_OR_TRG4BN = 7, // MTU4 TADCORA or MTU4 TADCORB
ADC_TRIG_SYNC_TPUTRG0AN = 8, // TPU0 TRGA
ADC_TRIG_SYNC_TMRTRG0AN = 9, // TMR0 TCORA
ADC_TRIG_SYNC_TMRTRG2AN = 10, // TMR2 TCORA
ADC_TRIG_SOFTWARE = 16 // software trigger(This is not set to ADSTRS)
} adc_trig_t;
typedef enum e_adc_add
{
ADC_ADD_OFF = 0, // addition is turned off for chans/sensors
ADC_ADD_TWO_SAMPLES = 1,
ADC_ADD_THREE_SAMPLES = 2,
ADC_ADD_FOUR_SAMPLES = 3
} adc_add_t;
typedef enum e_adc_align
{
ADC_ALIGN_RIGHT = 0x0000,
ADC_ALIGN_LEFT = 0x8000
} adc_align_t;
typedef enum e_adc_clear
{
ADC_CLEAR_AFTER_READ_OFF = 0x0000,
ADC_CLEAR_AFTER_READ_ON = 0x0020
} adc_clear_t;
typedef enum e_adc_speed
{
ADC_CONVERT_SPEED_PCLK_DIV8 = 0x00,
ADC_CONVERT_SPEED_PCLK_DIV4 = 0x01,
ADC_CONVERT_SPEED_PCLK_DIV2 = 0x02,
ADC_CONVERT_SPEED_PCLK = 0x03
} adc_speed_t;
