RX Family ADC Module Using Firmware Integration Technology
R01AN1666EJ0220 Rev. 2.20 Page 43 of 74
Dec 01, 2016
#define ADC_SST_SH_CNT_DEFAULT (24) // default sample&hold states
typedef struct st_adc_ch_cfg // bit 0 is ch0; bit 15 is ch15
{
uint32_t scan_mask; // channels/bits 0-15
uint32_t scan_mask_groupb; // valid for group modes
adc_grpa_t priority_groupa; // valid for group modes
uint32_t add_mask; // valid if add enabled in Open()
adc_diag_t diag_method; // self-diagnosis virtual channel
bool anex_enable; // unit1: use external amplifier
uint8_t sample_hold_mask; // channels/bits 0-2
uint8_t sample_hold_states; // minimum .4us
} adc_ch_cfg_t;
/* for ADC_CMD_EN_COMPARATOR_LEVEL and ADC_CMD_EN_COMPARATOR_WINDOW */
typedef struct st_adc_cmpwin_cfg // bit-OR ADC_MASK_xxx to
{ // indicate channels/sensors
uint32_t compare_mask; // channels/sensors to compare
uint32_t inside_window_mask; // condition met when within range
// default=0 met when outside range
uint16_t level_lo;
uint16_t level_hi;
uint8_t int_priority; // S12CMPI priority level
// 1=low 15=hi 0=polled
} adc_cmpwin_t;
/***** ADC_READ() ARGUMENT DEFINITIONS *****/
typedef enum e_adc_reg
{
ADC_REG_CH0 = 0,
ADC_REG_CH1 = 1,
ADC_REG_CH2 = 2,
ADC_REG_CH3 = 3,
ADC_REG_CH4 = 4,
ADC_REG_CH5 = 5,
ADC_REG_CH6 = 6,
ADC_REG_CH7 = 7, // last channel unit0
ADC_REG_CH8 = 8,
ADC_REG_CH9 = 9,
ADC_REG_CH10 = 10,
ADC_REG_CH11 = 11,
ADC_REG_CH12 = 12,
ADC_REG_CH13 = 13,
ADC_REG_CH14 = 14,
ADC_REG_CH15 = 15,
ADC_REG_CH16 = 16,
ADC_REG_CH17 = 17,
ADC_REG_CH18 = 18,
ADC_REG_CH19 = 19,
ADC_REG_CH20 = 20,
ADC_REG_TEMP,
ADC_REG_VOLT,
// both units
ADC_REG_DBLTRIG,
ADC_REG_DBLTRIGA, // loaded when first multi-source trigger was A
ADC_REG_DBLTRIGB, // loaded when first multi-source trigger was B
ADC_REG_SELF_DIAG,
