Renishaw NC4 Installation And Maintenance Guide

25Installation – separate system
Typical mounting details
3-plate adjuster packSingle-plate adjuster pack
4 holes M4 × 0.7 P ×
10 mm deep (minimum)
Ø30 (Ø1.18)
38 min.
(1.50 min.)
16 min.
(0.63 min.)
13 (0.51)
18
(0.71)
18
(0.71)
21.5
(0.85)
21.5
(0.85)
30 min.
(1.18 min.)
60 min. (2.36 min.)
1
(0.04)
Ø30 (Ø1.18)
21.5
(0.85)
21.5
(0.85)
30 min.
(1.18 min.)
60 min. (2.36 min.)
16 min.
(0.63 min.)
1
(0.04)
2 holes M4 × 0.7 P ×
10 mm deep (minimum)
