26 Installation – separate system
Ø4 mm blanking plug
Ø3 mm air pipe
(from NC4 unit)
Ø3 mm-to-Ø4 mm
straight adaptor
(step 4 refers)
NC4 unit
Mounting plate A
M3 holding screws
(steps 5 and 6 refer)
