02
2. Extension (adapted to TH012/TH013 models)
2.1 Extension diagram
1.3 Host installation method
1.3.1 Flat installation: Place the
host at on the desktop to
complete the installation. Note:
There is no need to place a back
clip on the back of the host at this
time;
1.3.2 Wall-mounted installation: Lock
the host to the wall through the nail
hole of the back clip to complete the
installation;
1.ASK: 433.92MHz;
2.WiFi:
2.400-2.4835GHz&5.150-5.
850GHz, 802.11b/g/n
standard
>100m (open space)
Max 10mW
Max 24
>90dB
1
2
1. Lanyard position
2. Function buttons
7 Communication method
8
Communication distance
9
Transmit power
10
Number of connectable
extensions
11 Alarm volume
