-Do not use the portable antenna or headphone cable while carrying or using the product.
-When the accessory is not in use, please cover the accessory connector cover.
Cleaning
Use a clean and dry lint-free cloth or brush to wipe off the dust and dirt on the surface of the radio and the battery
pole piece periodically.
-The radio's buttons, control knobs, and housing are highly susceptible to dirt. Do not use chemicals such as
detergents, alcohols, aerosols or petroleum agents to avoid damage to the product surface and housing.
-After cleaning, make sure that the radio is thoroughly dry, otherwise, please do not use it.
Note: Before cleaning, please turn off the machine and remove the battery.
05
Frequency Range PMR446
Memory Channel 16
audio distortion <5%
Operation Temperature Range －20℃+55℃
Antenna Impendance 50Ω
Output power ≤0.5W
frequency stability ±2.5ppm
maximum frequency deviation ≤±2.5kHz@12.5KHZ
stray radiation ≤-57dBm
Modulation type 11 K0F3E@12.5KHz
Current ≤750mA
Receiver sensitivity Analog≤-121dBm@12dB SINAD ; Digital≤-119dBm@5% BER
Adjacent channel selectivity ≥60dB
Inter-modulation 65dB
Rated Voltage DC 3.7V
Technical Specifications
