REVENT RVM80 - Page 20

19
4.) Tuck wires into wall enclosure and fasten the CONTROL to the wall enclosure
with the two screws provided.
power to fan
ground
120V line AC
CONTROL BACK
wall
enclosure
MOUNTING
SCREW
Qty:2
WIRE
NUT
Qty:4
MUSIC
FAN
ReVent
®
FSM-80
product of GTR Technologies Inc.
USA and international patents pending.
Electrical Input: 120 volts @ 60Hz
Maximum Fan Load: 6 Amps
This switch is only to be used with
ReVent fan model RVM80
Must Be Mounted Inside A Code
Approved Electrical Outlet Box
Made In China
CONTROL FRONT
red
black
white
green
