REVENT RVS50 - Page 12

11
Match wire colors as shown:
line
ground
FAN
ground
housing
ground
line in
neutral
neutral
line in
FAN
FAN
fan switch
(purchased separately)
SWITCH NOT INCLUDED, MUST BE PURCHASED SEPARATELY
Always follow all safety instructions included with the switch you purchase. Do not
exceed maximum electrical ratings.
ReVent fan
120V line AC
white
ground
fan
black
black
