27
Pedal adjustment including "Quick Change
The optional "Quick Change" pedal adjustment allows easy adjustment of brake and pillion footrests by screwing them on once and without the use of tools. On
Touring-equipped models, the widest adjustment option is locked, as the pedal would otherwise hit the leg fairing (yellow ring).
Pedal adjustment without "Quick Change
On vehicles with bolted pedal adjustment, you have the option of adjusting the brake to your body size in two or three stages. To do this, pull out the
spring-assisted bolt and move both pedals to the desired position.
Make sure that the bolt is fully engaged after adjustment and that the locking pin is in the correct position.
Please have the pedal adjustment carried out by a rewaco specialist workshop, as certain settings for the fastening must be observed. (The tightening torque
of the screw connection is 28 Nm).
Blocked position for touring models
Functions and settings
