Deskside and Office 230vissue7 7 01/02/02
ILLUSTRATED PARTS MANUALS
SERIES 7 SHREDDERS – 230v
DESKSIDE AND OFFICE MODELS
No Description Part S3 S4 Comments
36 Nut protection cap SL18-325 2 2
37 Infeed Chute (front) D53035 1 1
38 Not used
39 Stripper Cross Cut D53010 144
39 Stripper Cross Cut D53086 138
40 Cutter shaft – Driven D53018 1
40 Cutter shaft – Driven D53020 1
41 Key 5X5X16 KEY32 2 2
42 Cutter Shaft – Drive D53019 1
42 Cutter Shaft – Drive D53021 1
43 Key, Woodruff KEY33 1 1
END PLATE
ASSEMBLY
A53526SP 1 1 Comprises 8,10,11
GEARBOX SPACER
ASSEMBLY
A53531SP 1 1 Comprises 6,7
SIDE FRAME ASS.
(BEARING)
A53041SP 1 Comprises 31,32,27
SIDE FRAME ASS
(MOTOR)
A53042SP 1 Comprises 1,11,32,27
CUTTING HEAD
ASSEMBLY
A53060SP 1
Comprises all except 17,21,22,28,30,13
CUTTING HEAD
ASSEMBLY
A53061SP 1
Comprises all except 17,21,22,28,30,13
SIDE FRAME ASS.
(MOTOR)
A53069SP 1 Comprises 31,32,27
SIDE FRAME ASS.
(BRG)
A53071SP 1 Comprises 31,32,27
SHREDDER OIL, 500
ML
40100 1 1
