14
I.D. Description Size Q’ty I.D. Description Size Q’ty
086G INSERT 1 0J7B FLAT WASHER
5/16*25/32-1/8
2
086H CHAIN 1 0J95 SPRING WASHER φ6 2
086K SPROCKET 2 0JEV E-RING 4
086L BEARING COVER 2 0JPF HEX. HD. BOLT M6*1.0-25 4
086M BASE 1 0JQ1 HEX. HD. BOLT M10*1.5-45 4
086N GUIDE PLATE 2 0JZY HEX. SOC. TRUSS HD. SCREW M6*1.0-12 2
086P TABE PLATE 1 0K33
CR. RE. PAN HD. SCREW & WASHER
M4*0.7-8 2
086S SCREW BAR 2 0K3H
CR. RE. PAN HD. SCREW & WASHER
M6*1.0-12 14
086T SUPPORT 4 0K47
CR. RE. PAN HD. SCREW & WASHER
M6*1.0-20 1
086X SCALE 1 0K56 CR. RE. COUNT HD. SCREW M5*0.8-12 2
0870 EXTENTION WING ASS’Y 2 0KMS HEX. NUT M6*1.0 T=5 4
0874 ROLLING WHEEL 2 0KQX NUT M6*1.0 T=6 2
0875 SHAFT SLEEVE 4 0KQY LOCK NUT M8*1.25 T=8 2
0876 SHAFT 2 0XBF PLATE COVER 1
0877 SPRING PLATE 2 0XBG PLATE COVER 1
087G ARM BRACKET 1 10TD KNOB 1
087H SPACER 1 2111 CUSHION 2
087K HANDLE 1 2113 SET BOLT 2
087N LINK BAR 2 2116 TENSIONH ANDLE 1
087Q SLEEVE 2 2118 TENSION HANDLE 1
088E NUT 2 211E BASE 4
08A5 SETTING GAUGE 2 21CD CAUTION LABEL 1
0GGJ HEX. WRENCH 1 21XQ
CR. RE. ROUND WASHER HD. SCREW
M6*1.0-60 4
0HVM
BALL BEARING 2 22A4 LOCKING CABLE TIE 2
0J3P HEX. WRENCH 1 26DP SPECIAL BOLT 4
0J4E FLAT WASHER φ6*13-1 2 36DX INSTRUCTION MANUAL 1
0J78 FLAT WASHER 1/4*1/2-3/32 6 370V POWER CABLE ASS’Y 1
ORDER ONLY BY MODEL NUMBER AND PART NUMBER
AP3300 PARTS LIST (B)
