16
ORDER ONLY BY MODEL NUMBER AND PART NUMBER
AP3300 MOTOR PARTS LIST
I.D. Description Size Q’ty I.D. Description Size Q’ty
0JB9 WAVE WASHER BWW-6201 1 148G GEAR BOX 1
0JEA C-RING 1 148H HERIX GEAR 1
0JEE C-RING 1 148J GEAR SHAFT 1
0JGW PARALLEL KEY 1 148K HERIX GEAR 1
0JX4 HEX. SOC. SET SCREW M5*0.8-12 2 148L PIN 2
0KDZ CR. RE. PAN HD. SCREW M6*1.0-35 2 148M FRONT END BELL 1
0KQM
SQUARE NUT M6*1.0 T=5 2 148N SHAFT SLEEVE 4
0QM2
BRUSH HOLDER ASS’Y 2 148P GEAR SHAFT 1
0QQU CARBON BRUSH ASS’Y 2 148Q HERIX GEAR 1
0QR0 BRUSH COVER 2 148R FLOW GUIDE 1
0QR1 RUBBER PIN 1 156J MOTOR COVER 1
129D PARALLEL KEY 2 157N ARMATURE ASS'Y 1
1468 CR. RE. PAN HEAD TAPPING M5*12-70 2 1599 FIELD ASS'Y 1
& WASHER SCREW Y48Y CR. RE. PAN HD. & WASHER M6*1.0-78 2
148E MOTOR HOUSING 2 SCREW
148F TRANSIT SHAFT 1
