20/60 About this product
Bosch Rexroth AG, A6VE Series 65 and 71, RE 91616-01-B/10.2014
5.3 Product identification
The axial piston unit can be identified from the name plate. The following example
shows an A6VEname plate:
CNR:
MNR:
SN:
FD:
Rotation:
DE - 89275 Elchingen
Made in Germany
X1234567890Y
R90XXXXXXX
SC: X
12345678
Rexroth
2013W15
m XXX kg
7202
Typ: A6VE085EP600P000A/71MWV0Y2Z9100-0
1
2
3
4
5
6
13
12
11
10
9
V
g min
= XXX,X cm
3
78
Fig. 3: Name plate A6VE
1 Manufacturer
2 Sample category (optional)
3 Internal plant designation
4 Specified area for test stamp
5 Direction of rotation (looking at
driveshaft) – here: bi-directional
6 Weight (optional)
7 Barcode
8 Minimum displacement
9 Production date
10 Serial number
11 Material number of the axial
pistonunit
12 Ordering code
13 Customer material number
