Transport and storage 21/60
RE 91616-01-B/10.2014, A6VE Series 65 and 71, Bosch Rexroth AG
6 Transport and storage
▶ Always observe the required ambient conditions for transport and storage, see
chapter6.2 “Storing the axial piston unit” on page 23.
Notes on unpacking can be found in chapter7.1 “Unpacking” on page25.
6.1 Transporting the axial piston unit
The following transportation options are available depending on the weight and
duration of transport:
• Transport by hand (chapter not relevant for this axial piston unit)
• Transporting with lifting device (eye bolt or lifting strap)
Table 6: Dimensions and weights A6VE series 65
Size 55 80 107 160
Weight without BVI kg 26 34 47 64
Weight with BVI kg 35 43 53 72
Width mm The dimensions vary with the unit type. The values applicable for your
axial piston unit can be found in the installation drawing (request if
necessary).
Height mm
Depth mm
Table 7: Dimensions and weightsA6VESeries 71
Size 60 85 115 170
Weight without BVI kg 28 36 46 62
Weight with BVI kg 37 45 52 70
Width mm The dimensions vary with the unit type. The values applicable for your
axial piston unit can be found in the installation drawing (request if
necessary).
Height mm
Depth mm
The weight specifications may vary depending on the unit type.
6.1.1 Transporting by hand
Axial piston units with a weight of up to 15 kg can be transported manually for a
short time if necessary.
CAUTION! Danger from heavy loads!
There is a danger of health damage when carrying axial piston units.
▶ Use suitable lifting, placement and relocation equipment.
▶ Use your personal protective equipment (e.g., safety glasses, safety gloves,
suitable working clothes, safety shoes).
▶ Do not transport the axial piston unit at sensitive attachment parts
(e.g. sensors or valves).
▶ Carefully place the axial piston unit on the seating to prevent it from being damaged.
