REXROTH A6VE Series 71 User Manual

Installation 27/60
RE 91616-01-B/10.2014, A6VE Series 65 and 71, Bosch Rexroth AG
7.3 Installation position
The following installation positions are permissible. The shown piping layout
illustrates the basic layout.
7.3.1 Below-reservoir installation (standard)
Below-reservoir installation is when the axial piston unit is installed outside of the
reservoir below the minimum fluid level.
Recommended installation position: 1 and 2.
1 2
3
T
2
, T
1
h
t min
h
min
h
t min
h
min
h
t min
h
min
T
2
, T
1
T
2
, T
1
Fig. 6: Below-reservoir installation A6VE with installation position 1–3
T
1
, T
2
Highest level drain port
h
min
Minimum required spacing to
reservoir base (100 mm)
h
t min
Minimum necessary immersion depth
(200 mm)
Table 9: Below-reservoir installation
Installation position Air bleeding Filling
1 (drive shaft, horizontal) – T
2
, T
1
2 (drive shaft, horizontal) – T
2
, T
1
3 (drive shaft vertically downward) – T
2
, T
1
