28/60 Installation
Bosch Rexroth AG, A6VE Series 65 and 71, RE 91616-01-B/10.2014
7.3.2 Above-reservoir installation
Above-reservoir installation means the axial piston unit is installed above the
minimum fluid level of the reservoir.
T
2
, T
1
T
2
, T
1
T
2
, T
1
4 5
6
L
1
L
1
L
1
h
t min
h
min
h
t min
h
min
h
t min
h
min
Fig. 7: Above-reservoir installation A6VE with installation position 4–6
L
1
Filling / air bleeding
Note: L
1
is part of the external piping
h
t min
Minimum necessary immersion depth
(200 mm)
T
1
, T
2
Highest level drain port
h
min
Minimum required spacing to
reservoir base (100 mm)
Table 10: Above-reservoir installation
Installation position Air bleeding Filling
4 (drive shaft, horizontal) L
1
T
2
, T
1
(L
1
)
5 (drive shaft, horizontal) L
1
T
2
, T
1
(L
1
)
6 (drive shaft vertically downward) L
1
T
2
, T
1
(L
1
)
