38/60 Installation
Bosch Rexroth AG, A6VE Series 65 and 71, RE 91616-01-B/10.2014
Table 16: Tightening torques for female threads and threaded plugs
Ports
Maximum permissible
tightening torque of the
threaded holes M
Gmax
Required tightening torque of
the threaded plugs M
V
WAF hexagon socket of the
threaded plugs
Standard Threaded size
ISO 6149 M8 x 1 10 Nm 7 Nm 4 mm
M10 x 1 30 Nm 15 Nm 5 mm
M12 x 1.5 50 Nm 25 Nm 6 mm
M14 x 1,5 80 Nm 45 Nm 6 mm
M16 x 1.5 100 Nm 55 Nm 8 mm
M18 x 1,5 140 Nm 70 Nm 8 mm
M20 x 1,5 170 Nm 80 Nm 10 mm
M22 x 1.5 210 Nm 100 Nm 10 mm
M27 x 2 330 Nm 170 Nm 12 mm
M30 x 2 420 Nm 215 Nm 17 mm
M33 x 2 540 Nm 310 Nm 17 mm
M42 x 2 720 Nm 330 Nm 22 mm
M48 x 2 900 Nm 420 Nm 22 mm
DIN 3852
1)
M8 x 1 10 Nm 7 Nm 3 mm
M10 x 1 30 Nm 15 Nm
2)
5 mm
M12 x 1.5 50 Nm 25 Nm
2)
6 mm
M14 x 1,5 80 Nm 35 Nm 6 mm
M16 x 1.5 100 Nm 50 Nm 8 mm
M18 x 1,5 140 Nm 60 Nm 8 mm
M22 x 1.5 210 Nm 80 Nm 10 mm
M26 x 1.5 230 Nm 120 Nm 12 mm
M27 x 2 330 Nm 135 Nm 12 mm
M33 x 2 540 Nm 225 Nm 17 mm
M42 x 2 720 Nm 360 Nm 22 mm
M48 x 2 900 Nm 400 Nm 24 mm
1)
The tightening torques of the M
V
threaded plugs apply for the screws in the “dry” state received on delivery and for the “lightly oiled”
state for installation.
2)
In the “lightly oiled” state, M
V
is reduced to 10 Nm or M10 x 1 to 17 Nm for M12 x 1.5. For the delivery condition “dry” and for
reduced M
V
, 10Nm for M10x1 and 17Nm for M12x1.5, the maximum permissible pressure is 420bar.
To connect the axial piston unit to the hydraulic system:
1. Remove the protective plugs and threaded plugs at the ports at which the
connections are to be made according to the hydraulic circuit diagram.
2. Make certain that the sealing surfaces of the hydraulic ports and functional
surfaces are not damaged.
3. Use only clean hydraulic lines or flush them before installation. (Note chapter7.5
“Performing flushing cycle” on page 40 when you flush out the complete
system.)
4. Connect the lines in accordance with the installation drawing and the machine or
system circuit diagram. Check whether all ports are connected or plugged with
threaded plugs.
5. Tighten the fittings correctly (note tightening torques). Mark all correctly
tightened fittings, e.g. with a permanent marker.
Procedure
