Commissioning 41/60
RE 91616-01-B/10.2014, A6VE Series 65 and 71, Bosch Rexroth AG
8 Commissioning
WARNING
Danger while working in the danger zone of a machine/system!
Danger to life, risk of injury or serious injuries!
▶ Pay attention to and rectify potential danger sources before operating the axial
piston unit.
▶ Nobody may stand in the danger zone of the machine/system.
▶ The emergency stop button for the machine/system must be within the
operator’s reach.
▶ Always follow the instructions of the machine/system manufacturer during
commissioning.
CAUTION
Commissioning of an incorrectly installed product!
Risk of injury and damage to equipment!
▶ Make sure that all electrical and hydraulic ports are connected or plugged.
▶ Only commission a completely installed fault-free product with original
accessories from Bosch Rexroth.
8.1 Initial commissioning
During all work for commissioning the axial piston unit, observe the general
safety instructions and intended use detailed in chapter 2 “Safety instructions”
on page8.
▶ Connect the gauge for the operating pressure and case pressure to the specified
measuring points on the axial piston unit or in the hydraulic system, to check the
technical data at first operation.
▶ During the commissioning process, monitor the temperature of the hydraulic fluid
in the reservoir to ensure that it lies within the permissible viscosity limits.
8.1.1 Filling the axial piston unit
Professional filling and air bleeding is necessary to prevent damage to the axial
piston unit and to maintain correct function.
The axial piston unit should be filled with a filling unit (10 µmfilter grade).
The axial piston unit must not be operated while it is being filled by the filling unit.
