REXROTH IndraDyn A Series User Manual

6-4 Type Codes Rexroth IndraDyn A
6.2 Type Code for MAD100
1. Product
1.1 MAD . . . . . . . = MAD
2. Size
2.1 100 . . . . . . . . . . . . . . = 100
3. Length
3.1 Lengths . . . . . . . . . . . . = B, C, D
4. Winding
4.1 MAD100B = 0050, 0100, 0150, 0200, 0250
4.2 MAD100C = 0050, 0100, 0150, 0200, 0250
4.3 MAD100D = 0050, 0100, 0150, 0200, 0250
5. Cooling
5.1 Axial fan, blowing . . . . . . . . . . . . . . . . . . . . . = SA
6. Encoder
6.1 Singleturn absolute encoder with 512 increments = S0
6.2 Singleturn absolute encoder, EnDat2.1, with
2048 increments . . . . . . . . . . . . . . . . . . . . . . . . . . = S2
6.3 Multiturn absolute encoder with 512 increments = M0
6.4 Multiturn absolute encoder, EndDat2.1, with
2048 increments . . . . . . . . . . . . . . . . . . . . . . . . . . . = M2
6.5 Incremental encoder with 2048 increments . . . . . . = C0
6.6 without motor encoder . . . . . . . . . . . . . . . . . . . . . . = N0
7. Electrical connection
7.1 Connector, A-side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = A
7.2 Connector, B-side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = B
7.3 Connector, right . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = R
7.4 Connector, left . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = L
7.5 Terminal box connection, A-side . . . . . . . . . . . . . . . . . . . . = F
7.6 Terminal box connection, B-side . . . . . . . . . . . . . . . . . . . . = K
8. Shaft
with key
plain
balanced with balanced with
shaft entire key half key
8.1 without shaft sealing ring HQ L
8.2
with shaft sealing ring GP K
1234 6789
1
05 1234 6789
2
05 1234 6789
3
05 1234 6789
4
05
Example:
Abbrev.
Column
MAD100C- 0100 -SA-S0-BH0 - 05-N1
1
2
2
RNC-41171-000_NOR_E_D0_2004-11-153.EPS
Fig. 6-4: Type code for MAD100 (1/2)
