Rexroth IndraDyn A Type Codes 6-11
1234 6789
1
05 1234 6789
2
05 1234 6789
3
05 1234 6789
4
05
Example:
Abbrev.
Column
MAD180C- 0050 -SA-C0 -KH0 - 35-N1
10. Mounting style
10.1 Flange and foot mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = 35
11. Bearings
11.1 Standard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = N
11.2 reinforced bearings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = V
11.3 for clutch mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = R
12. Vibration severity grade
12.1 R . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = 1
12.2 S . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = 2
12.3 S1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = 3
Note:
Looking from front onto driven shaft (see picture 1)
Electrical connection "F" and "K" at mounting style "35" is only available on top
Vibration severity grade "S1" is not available with bearings "V"
3
2
1
Picture 1
Position of power connection = top
B-side
right
left
A-side
3
RNC-41171-800_NOR_E_D0_2004-09-154.EPS
Fig. 6-11: Type code for MAD180 (2/2)
