6-12 Type Codes Rexroth IndraDyn A
6.6 Type Code for MAF100
1. Product
1.1 MAF . . . . . . . = MAF
2. Size
2.1 100 . . . . . . . . . . . . . . = 100
3. Length
3.1 Lengths . . . . . . . . . . . . = B, C, D
4. Winding
4.1 MAF100B = 0050, 0100, 0150, 0200, 0250
4.2 MAF100C = 0050, 0100, 0150, 0200, 0250
4.3 MAF100D = 0050, 0100, 0150, 0200, 0250
5. Cooling
5.1 Liquid cooling with connection thread 1/4" = FQ
5.2
Liquid cooling with rapid action coupling 1/4" = FR
6. Encoder
6.1 Singleturn absolute encoder with 512 increments = S0
6.2 Singleturn absolute encoder, EnDat2.1, with 2048
increments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = S2
6.3 Multiturn absolute encoder with 512 increments = M0
6.4 Multiturn absolute encoder with, EnDat2.1, 2048
increments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = M2
6.5 Incremental encoder with 2048 increments . . . . . . = C0
6.6 without motor encoder . . . . . . . . . . . . . . . . . . . . . . = N0
7. Electrical connection
7.1 Connector, A-side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = A
7.2 Connector, B-side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = B
7.3 Connector, right . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = R
7.4 Connector, left . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = L
7.5 Terminal box connection, A-side . . . . . . . . . . . . . . . . . . . = F
7.6 Terminal box connection, B-side . . . . . . . . . . . . . . . . . . . = K
8. Shaft
with key
plain
balanced with balanced with
shaft entire key half key
8.1 without shaft sealing ring HQ L
8.2
with shaft sealing ring GP K
1234 6789
1
05 1234 6789
2
05 1234 6789
3
05 1234 6789
4
05
Example:
Abbrev.
Column
MAF100C- 0150-FQ-S0 -AP0 -05 -N1
1
2
2
RNC-41181-000_NOR_E_D0_2004-11-153.EPS
Fig. 6-12: Type code for MAF100 (1/2)
