REXROTH IndraDyn A Series User Manual

6-18 Type Codes Rexroth IndraDyn A
6.9 Type Code for MAF180
1. Product
1.1 MAF . . . . . . . = MAF
2. Size
2.1 180 . . . . . . . . . . . . . . = 180
3. Length
3.1 Lengths . . . . . . . . . . . . . . = C, D
4. Winding code
4.1 MAF180C . . . = 0050, 0100, 0150, 0200
4.2 MAF180D . . . = 0050, 0100, 0150, 0200
5. Cooling mode
5.1 Liquid cooling with connection thread 1/2" = FQ
5.2
Liquid cooling with rapid action coupling 1/2" = FR
6. Motor encoder
6.1 singleturn absolute encoder with 512 increments = S0
6.2 singleturn absolute encoder, EnDat2.1, with
2048 increments . . . . . . . . . . . . . . . . . . . . . . . . . . . = S2
6.3 multiturn absolute encoder with 512 increments = M0
6.4 multiturn absolute encoder, EnDat2.1, with
2048 increments . . . . . . . . . . . . . . . . . . . . . . . . . . . = M2
6.5 incremental encoder with 2048 increments . . . . . . = C0
6.6 without motor encoder . . . . . . . . . . . . . . . . . . . . . . = N0
7. Electrical connection
7.1 Terminal box connector, A-side . . . . . . . . . . . . . . . . . . . . . = F
7.2 Terminal box connector, B-side . . . . . . . . . . . . . . . . . . . . . = K
8. Output shaft
with key
plain
balanced with balanced with
shaft entire key half key
8.1 without shaft seal. ring HQ L
8.2 with shaft seal. ring G P K
9. Holding brake
9.1 without holding brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = 0
9.2 electrically-released, 240 Nm . . . . . . . . . . . . . . . . . . . . . . . . . . = 2
9.3 electrically-clamped, 300 Nm . . . . . . . . . . . . . . . . . . . . . . . . . . = 5
1234 6789
1
05 1234 6789
2
05 1234 6789
3
05 1234 6789
4
05
Example:
Abbrev.
Column
MAF180C- 0050 -FQ-C0 -CH0 - 35 -N1
21
RNC-41181-800_NOR_E_D0_2004-09-153.EPS
Abb. 6-18: Type code for MAF180 (1/2)
