Rexroth IndraDyn A Handling and Transportation 10-1
10 Handling and Transportation
10.1 Delivery status
IndraDyn A motors are delivered in wooden crates or in cartons. Packing
units on pallets are secured by metal band.
CAUTION
Injuries due to uncontrolled movement of the
metal band when cutting!
⇒ Maintain a sufficient distance and carefully cut the
metal band.
On delivery from the factory, the motor drive shaft and the connectors
have protective sleeves. Remove the protective sleeves just before
assembly.
Factory Test
All IndraDyn A motors undergo the following inspections, among others,
at the factory:
• High-voltage test according to EN 60034-1 (= VDE 0530-1).
• Insulation resistance according to EN 60204-1/1.92, Section 20.3.
• Protective earth conductor connection according to EN 60204-1/1.92,
Section 20.3.
• Concentricity and position tolerances of shaft end and mounting flange
according to DIN 42955.
• Vibration measurement according to DIN 2373.
Inspection Tests by the Customer
Since all IndraDyn A motors undergo a standardized inspection
procedure, high-voltage tests by the customer are not required. Motors
and components could be damaged if they undergo several high-voltage
tests.
CAUTION
Destruction of motor components by
improperly-executed high-voltage test! Loss of
warranty!
⇒ Avoid repeated inspections.
⇒ Observe the regulations of EN 60034-1
(= VDE 0530-1).
Electrical Test
Mechanical Test
