Rexroth IndraDyn A Technical Data 4-9
Characteristic Curves of MAD100C
MAD100C-0050
0,0
20,0
40,0
60,0
80,0
100,0
120,0
0
500
1000 1500 2000 2500 3000
Drehzahl/speed [min-1]
Drehmoment/Torque [Nm]
0
0,5
1
1,5
2
2,5
3
3,5
4
4,5
Leistung/power [kW]
KENNL-MAD100C_0050.FH10
Mit Regelgerät HMS01.1N-W0020 an Versorger HMV01.1E-W0120 an 3xAC400V (-5%)
With Drive Controller HMS01.1N-W0020 at HMV01.1E-W0120 with main connection 3xAC400V (-5%)
M
max
M
nenn
P
max
P
nenn
Fig. 4-12: Characteristic curve of MAD100C-0050
KENNL-MAD100C_0100.FH10
Mit Regelgerät HMS01.1N-W0036 an Versorger HMV01.1E-W0120 an 3xAC400V (-5%)
With Drive Controller HMS01.1N-W0036 at HMV01.1E-W0120 with main connection 3xAC400V (-5%)
MAD100C-0100
0,0
20,0
40,0
60,0
80,0
100,0
120,0
140,0
0
500
1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000
Drehzahl/speed [min-1]
Drehmoment/Torque [Nm]
0
1
2
3
4
5
6
7
8
9
10
Leistung/power [kW]
M
max
M
nenn
P
max
P
nenn
Fig. 4-13: Characteristic curve of MAD100C-0100
