Rexroth IndraDyn A Technical Data 4-15
MAD100D-0250
0,0
20,0
40,0
60,0
80,0
100,0
120,0
140,0
0
500
1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000 6500 7000 7500 8000 8500 9000
Drehzahl/speed [min-1]
Drehmoment/Torque [Nm]
0
5
10
15
20
25
Leistung/power [kW]
M
max
M
nenn
P
max
P
nenn
KENNL-MAD100D_0250.FH10
Mit Regelgerät HMS01.1N-W0070 an Versorger HMV01.1E-W0120 an 3xAC400V (-5%)
With Drive Controller HMS01.1N-W0070 at HMV01.1E-W0120 with main connection 3xAC400V (-5%)
Fig. 4-22: Characteristic curve of MAD100D-0250
