REXROTH IndraDyn A Series User Manual

4-18 Technical Data Rexroth IndraDyn A
MAD130B-0150
0,0
50,0
100,0
150,0
200,0
250,0
0
500
1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000 6500 7000 7500
Drehzahl/speed [min-1]
Drehmoment/Torque [Nm]
0
5
10
15
20
25
30
Leistung/power [kW]
M
max
M
nenn
P
max
P
nenn
KENNL-MAD130B_0150.FH10
Mit Regelgerät HMS01.1N-W0070 an Versorger HMV01.1E-W0120 an 3xAC400V (-5%)
With Drive Controller HMS01.1N-W0070 at HMV01.1E-W0120 with main connection 3xAC400V (-5%)
Fig. 4-26: Characteristic curve of MAD130B-0150
MAD130B-0200
0,0
20,0
40,0
60,0
80,0
100,0
120,0
140,0
160,0
180,0
200,0
0
500
1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000 6500 7000 7500
Drehzahl/speed [min-1]
Drehmoment/Torque [Nm]
0
5
10
15
20
25
30
35
Leistung/power [kW]
M
max
M
nenn
P
max
P
nenn
KENNL-MAD130B_0200.FH10
Mit Regelgerät HMS01.1N-W0150 an Versorger HMV01.1E-W0120 an 3xAC400V (-5%)
With Drive Controller HMS01.1N-W0150 at HMV01.1E-W0120 with main connection 3xAC400V (-5%)
Fig. 4-27: Characteristic curve of MAD130B-0200
