4-38 Technical Data Rexroth IndraDyn A
Characteristic Curves of MAD180D
MAD180D-0050
0,0
100,0
200,0
300,0
400,0
500,0
600,0
700,0
800,0
900,0
1000,0
0
500
1000 1500 2000 2500 3000
Drehzahl/speed [min-1]
Drehmoment/Torque [Nm]
0
5
10
15
20
25
30
35
40
Leistung/power [kW]
M
max
M
nenn
P
max
P
nenn
KENNL-MAD180D_0050.FH10
Mit Regelgerät HMS01.1N-W0150 an Versorger HMV01.1E-W0120 an 3xAC400V (-5%)
With Drive Controller HMS01.1N-W0150 at HMV01.1E-W0120 with main connection 3xAC400V (-5%)
Fig. 4-57: Characteristic curve of MAD180D-0050
MAD180D-0100
0,0
100,0
200,0
300,0
400,0
500,0
600,0
700,0
800,0
900,0
1000,0
0
500
1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000
Drehzahl/speed [min-1]
Drehmoment/Torque [Nm]
0,0
10,0
20,0
30,0
40,0
50,0
60,0
70,0
80,0
90,0
Leistung/power [kW]
M
max
M
nenn
P
max
P
nenn
KENNL-MAD180D_0100.FH10
Mit Regelgerät HMS01.1N-W0210 an Versorger HMV01.1E-W0120 an 3xAC400V (-5%)
With Drive Controller HMS01.1N-W0210 at HMV01.1E-W0120 with main connection 3xAC400V (-5%)
Fig. 4-58: Characteristic curve of MAD180D-0100
