REXROTH IndraDyn A Series User Manual

4-42 Technical Data Rexroth IndraDyn A
MAF100B-0150
0,0
20,0
40,0
60,0
80,0
100,0
120,0
0
500
1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000 6500 7000 7500 8000 8500 9000
Drehzahl/speed [min-1]
Drehmoment/Torque [Nm]
0
2
4
6
8
10
12
Leistung/power [kW]
M
max
M
nenn
P
max
P
nenn
KENNL-MAF100B_0150.FH10
Mit Regelgerät HMS01.1N-W0054 an Versorger HMV01.1E-W0120 an 3xAC400V (-5%)
With Drive Controller HMS01.1N-W0054 at HMV01.1E-W0120 with main connection 3xAC400V (-5%)
Fig. 4-64: Characteristic curve of MAF100B-0150
MAF100B-0200
0,0
10,0
20,0
30,0
40,0
50,0
60,0
70,0
80,0
90,0
100,0
0
500
1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000 6500 7000 7500 8000 8500 9000
Drehzahl/speed [min-1]
Drehmoment/Torque [Nm]
0
2
4
6
8
10
12
14
16
Leistung/power [kW]
M
max
M
nenn
P
max
P
nenn
KENNL-MAF100B_0200.FH10
Mit Regelgerät HMS01.1N-W0054 an Versorger HMV01.1E-W0120 an 3xAC400V (-5%)
With Drive Controller HMS01.1N-W0054 at HMV01.1E-W0120 with main connection 3xAC400V (-5%)
Fig. 4-65: Characteristic curve of MAF100B-0200
