4-54 Technical Data Rexroth IndraDyn A
MAF130B-0150
0,0
50,0
100,0
150,0
200,0
250,0
300,0
0
500
1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000 6500 7000 7500
Drehzahl/speed [min-1]
Drehmoment/Torque [Nm]
0
5
10
15
20
25
30
35
40
Leistung/power [kW]
M
max
M
nenn
P
max
P
nenn
KENNL-MAF130B_0150.FH10
Mit Regelgerät HMS01.1N-W0150 an Versorger HMV01.1E-W0120 an 3xAC400V (-5%)
With Drive Controller HMS01.1N-W0150 at HMV01.1E-W0120 with main connection 3xAC400V (-5%)
Fig. 4-71: Characteristic curve of MAF130B-0150
MAF130B-0200
0,0
50,0
100,0
150,0
200,0
250,0
0
500
1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000 6500 7000 7500
Drehzahl/speed [min-1]
Drehmoment/Torque [Nm]
0
5
10
15
20
25
30
35
40
45
Leistung/power [kW]
M
max
M
nenn
P
max
P
nenn
KENNL-MAF130B_0200.FH10
Mit Regelgerät HMS01.1N-W0150 an Versorger HMV01.1E-W0120 an 3xAC400V (-5%)
With Drive Controller HMS01.1N-W0150 at HMV01.1E-W0120 with main connection 3xAC400V (-5%)
Fig. 4-72: Characteristic curve of MAF130B-0200
